Channel Swing Gate

Model: RALID - 539 / RALID - 539D

System：Visitor Management System

The anti-collision swing gate features hall digital positioning with intelligent obstacle detection and automatic return function, ensuring safe passage by instantly reversing when resistance is detected. Its horizontal movement design optimizes space utilization, while the swing arms—crafted from 304 stainless steel or acrylic—balance durability and visual appeal. Engineered for outdoor environments, this gate is fully compatible with electric vehicles, making it an ideal solution for mixed-traffic access control in parking lots, communities, or commercial areas.

Electrical Parameters：

• Material: Brushed SUS304 stainless steel (1.0+1.2mm for chassis + upper cover)
• Power Supply: 220VAC ±10%/15%, 50HZ ±4%
• Drive Motor: DC motor, DC24V
• Drive Mode: Digital control
• Infrared Pairs: 6-8 pairs
• Working Environment: -25℃～+75℃
• Passage Speed: 30-35 persons/minute
• MTBF (Mean Time Between Failures): 3.5 million cycles
• Relative Humidity: 5%--90% (non-condensing)
• IP Rating: IP24 or higher (water and dust protection)
